Illuminated Panel Button Switch

The operating voltage of the 17x17.4MM illuminated push button switch for stage lighting console is usually 12V DC


The illumination on this switch is usually provided by LEDs. LEDs are the preferred light source in the industry as they are energy-efficient and long-lasting. The life of an LED is usually about 50,000 hours, which is equivalent to over five years of uninterrupted service – an essential feature for a console that may be used daily.

It is necessary to prevent switches from sticking or freezing due to dust or moisture. To prevent this, the switch is typically equipped with a waterproof rubber cover, which protects it from external contamination. The waterproof rubber material is also durable and flexible, ensuring the switch can operate seamlessly for long hours.

The operating voltage of the 17x17.4MM illuminated push button switch for stage lighting console is usually 12V DC, which is a standard voltage for devices in the stage lighting industry. The switch has a current rating of 10A/250VDC or 16A/125VAC. This means that it can be used with any device that has similar characteristics.

Installing the switch on a console is a straightforward process. First, the wiring diagram is checked to ensure that the switch is wired correctly. Second, the switch is mounted onto the console housing using screws. Care must be taken when mounting the switch so as not to damage the PCB or other components.

Finally, after the switch is securely mounted, the wiring is connected to the console wiring according to the wiring diagram. It is imperative to ensure that the wiring is done correctly as incorrectly wired switches can cause a significant safety risk.

In conclusion, the 17x17.4MM illuminated push button switch is an essential component in any stage lighting console. It provides the operator with easy access to the console and makes it easy for them to control the lighting. Its slim design, waterproof rubber cover, and LED illumination make it both easy to install and durable. With its standard voltage and current rating, it can be used with any device with similar characteristics.

For those in the lighting industry, investing in high-quality illuminated push button switches is vital to ensure that their stage lighting consoles function smoothly, without any hitches. As a whole, the 17x174MM illuminated push button switch is an essential tool that is widely used in the industry for its reliability, durability, and energy efficiency.

                                         Model                   PB86-B1ANR
                                         Product Item                   Tact Switch
                                         Switch Size                   17.4*17.0*mm
                                         Terminal no                   /
                                         Actuation Force                   250gf
                                         Function                   Momentary
                                         Terminal Style
                   T/T 100% in advance
                   15-20 workdays
                                         Shippment                   DHL/ FedEx /UPS



Illuminated Tactile switches, button switches, toggle switches, rocker switches, slide switches, microswitches, sockets and connectors, as well as hardware stamping and plastic injection.



Silicone tact switches are used in a wide range of electronic devices, including keyboards, remote controls, and game controllers. They are also used in medical equipment, such as ventilators and infusion pumps. The switches are also commonly used in control panels for instruments and certain appliances.


Rucoe Electronics is a leading manufacturer of illuminated switches which was established in 2013,our office is located in Shenzhen, and our factory in Dongguan which names Dongguan FVWIN Electronics Co.,Ltd. We provides high quality, high precision switches.with Innovative, Good quality management philosophy, strive hard to improve product design, tooling, injection molding technology, our product include in illuminated tact switch, push button switch, toggle switch, rocker switch, slide switch, DIP switch, wafer terminal ,AC & DC socket and connectors.





We have horizontal injection molding machine,punching machine,vertical milling machine,life tester,insulation resistance tester,salt spray tester,load curve meter,laser engraving machine.



Rucoe meets its customers' highest demands through certified quality, environmental and safety management systems;we also offer OEM and ODM etc strategic customized service.
