SPST Sub Mini Toggle Switch

The mini toggle switch with cap is a versatile and cost-effective switch that is easy to use and install.


A single-pole, single-throw subminiature toggle switch, or SPST submini toggle switch, is a type of switch that is often used in electronic circuits to control the flow of current. It is a small, compact switch that is typically mounted on a printed circuit board (PCB) and used for low-power applications. The switch features two positions – on and off – which are controlled by manually flipping the toggle lever.

SPST submini toggle switches are commonly used in a variety of devices and applications, including consumer electronics, audio equipment, telecommunications equipment, and more. They are known for their small size, low cost, and ease of use. In this article, we will discuss the construction, operation, and applications of SPST submini toggle switches.

SPST submini toggle switches are constructed of several key components, which include a toggle lever, a rocker arm, a spring, and a contact block. The toggle lever is the main control mechanism for the switch and is typically made of plastic or metal. The rocker arm is a small metal piece that is attached to the toggle lever and is used to make contact with the switch terminals. The spring applies pressure to the rocker arm, ensuring proper contact between the arm and the switch terminals. The contact block is attached to the switch body and contains the terminals that make contact with the rocker arm.

                                         Model                   TG-8019
                                         Product Item                   Toggle Switch
                                         Switch Function                   ON-OFF
                                         Stem Options                   Red/Blue/Black/Brown
                                         Type                   Tactile
                                         Function                   Momentary
                   0.1A 12VDC
                   T/T 100% in advance
                   15-20 workdays
                                         Shippment                   DHL/ FedEx /UPS




Tactile switches, button switches, toggle switches, rocker switches, slide switches, microswitches, sockets and connectors, as well as hardware stamping and plastic injection.



Applications of Subminiature Toggle Switches

Subminiature toggle switches are used in different electronic devices and circuits. They are particularly useful in applications where small size and low voltage and current are required. Here are some of the common applications:

1. Portable electronic devices

Subminiature toggle switches are ideal for use in portable electronic devices that require small switches. These devices include small-sized radios, calculators, and other small electronic gadgets.

2. Amplifiers

Subminiature toggle switches are also used in small electronic amplifiers that require low voltage and current. These amplifiers are commonly used in small speakers, headphones, and other audio devices.

3. Automotive applications

Subminiature toggle switches can be used in automotive applications such as dashboards, interior lights, and other electronic circuits in cars.

4. Industrial applications

Subminiature toggle switches are used in different industrial applications where small size and low voltage and current are required. These applications include control boxes, small machines, and other electronic circuits.
