Bi-color SMD LED tactile switches are electronic switches that combine the functionality of both tactile switches and LEDs in a single package.
Bi-color SMD LED tactile switches are electronic switches that combine the functionality of both tactile switches and LEDs in a single package. These switches provide tactile feedback while also lighting up when pressed. They are widely used in various electronic devices such as mobile phones, computer keyboards, industrial control panels, and gaming consoles.
The construction of a typical bi-color SMD LED tactile switch includes three main components: the switch mechanism, the LED package, and the SMD package. The switch mechanism is responsible for providing tactile feedback when pressed. It usually consists of a metal dome or a rubber dome that is mounted on top of a printed circuit board (PCB). When the switch is pressed, the dome collapses, and the contact point on the PCB is closed, completing the electrical circuit.
The LED package is responsible for emitting light when the switch is pressed. It is usually mounted on the same PCB as the switch mechanism. The LED can be either a single color (red, green, or blue) or a bi-color LED that can emit two different colors (red and green). In the case of bi-color SMD LED tactile switches, a single LED package is used, but it contains two different colors of LEDs that can be turned on and off independently.
The SMD package is a small surface mount package that holds the switch mechanism and the LED package together. It is designed to be mounted directly onto the PCB, eliminating the need for additional components such as leads or wires. The SMD package also provides protection for the switch mechanism and the LED from external damage.
One of the main advantages of bi-color SMD LED tactile switches is their space-saving design. These switches are small in size and can be mounted directly onto the PCB, making them ideal for devices with limited space. They also eliminate the need for additional components such as separate LEDs and tactile switches, reducing the overall cost of the device.
Another advantage of bi-color SMD LED tactile switches is their versatility. These switches are available in a variety of configurations, including momentary and latching types, with different actuation forces and travel distances. They can also be customized to meet specific design requirements, such as the color of the LED or the shape of the switch mechanism.
Bi-color SMD LED tactile switches are widely used in various electronic devices, including mobile phones, computer keyboards, and game controllers. In mobile phones, these switches are used as buttons for functions such as power on/off, volume control, and camera shutter. In keyboards, these switches are used as keys for typing and gaming. In game controllers, these switches are used as buttons for controlling the game.
In addition to their use in consumer electronics, bi-color SMD LED tactile switches are also used in industrial applications. These switches are commonly used in control panels and automation systems, where they provide reliable and durable operation in harsh environments.
Overall, bi-color SMD LED tactile switches are a versatile and cost-effective solution for adding both tactile feedback and lighting to electronic devices. With their small size, customizable design, and durable construction, these switches are an ideal choice for a wide range of applications.
|Product Item||Illuminated Tact Switch|
| Terminal Style||Surface Mount|
| Payment||T/T 100% in advance|
| Delivery||15-20 workdays|
|Shippment||DHL/ FedEx /UPS|
Illuminated Tactile switches, button switches, toggle switches, rocker switches, slide switches, microswitches, sockets and connectors, as well as hardware stamping and plastic injection.
Rucoe Electronics is a leading manufacturer of illuminated switches which was established in 2013，our office is located in Shenzhen, and our factory in Dongguan which names Dongguan FVWIN Electronics Co.,Ltd. We provides high quality, high precision switches.with Innovative, Good quality management philosophy, strive hard to improve product design, tooling, injection molding technology, our product include in illuminated tact switch, push button switch, toggle switch, rocker switch, slide switch, DIP switch, wafer terminal ,AC & DC socket and connectors.
We have horizontal injection molding machine,punching machine,vertical milling machine,life tester,insulation resistance tester,salt spray tester,load curve meter,laser engraving machine.
Rucoe meets its customers' highest demands through certified quality, environmental and safety management systems;we also offer OEM and ODM etc strategic customized service.
